Overview

This complete PET bottling line was manufactured between 2000 and 2012 by a group of reputable European manufacturers, including SIG Corpoplast, KHS, Sacmi, Kisters, Paxona, and others. The line is suitable for still and carbonated soft drinks and includes a blow moulder, filler, labeller, packer, and various conveyor and inspection systems. The line reaches up to 36,000 bph at 1.5L and is available promptly. All machines are well maintained and include original components and relevant peripheral equipment.

Technical data

• Capacity:
  • 36,000 bph at 1.5L water
  • 35,000 bph at 1.5L soft drinks (sweet)
  • 32,000 bph at 1.5L soft drinks (light)
• Formats:
  • 0.5L and 1.5L bottles
  • PCO 28-1881 closure
• Filling product:
  • Water and carbonated soft drinks (7.5g CO₂)
• Closure system:
  • Screw caps, fed via chute and tipper (Zalkin + NSM)
• Packing:
  • Shrink pack: 3x2 bottles (double lane)
• Pallet type:
  • Euro (1,200 x 800 mm)
  • Düsseldorfer (600 x 800 mm)
• Electrical specs:
  • 400 V / 50 Hz
  • Control systems: ABB, Siemens
• Operating direction: Standard

Scope of Delivery

• Blow moulder: SIG Corpoplast Blomax 24, year 2008
  • 24 stations, heating oven with 20 boxes, ABB control
  • Incl. Preform tipper MD3, preform hopper SBT, elevator HFT, conveyor RGTD, chute ASTK
• Air conveyor: NTS Mistral, year 2000
  • Pneumatic adjustable rails, basket cable tray
• Filler: KHS Innofill EV-VF, year 2000
  • 176 electronic filling valves, valve manifold (APV), air conveyor, infeed worm, clamping star wheel
  • Screw capper (Zalkin, 22 heads), cap feeding (NSM), foam cleaning (ECOLAB, 2001), dosing units (2011)
• Mixer / Deaeration: KHS Innopro DX65 Contimix 65/5-T20, year 2000
  • 65,000 l/h, 5 components, Brix meter (Anton Paar), Hilge pumps
• Labeller: Sacmi Opera 300 RF 26T/R S1E1, year 2012
  • 26 plates, hotmelt, wrap-around, reel-fed, parallel infeed, safety lift version
• Inspection & Coding:
  • Fill level and closure check: KHS Innocheck CUB Vision Circle, year 2013
  • Bottle laser coding: Videojet with housing
  • Pack inspection: KHS Innocheck CUB, year 2015
• Packing machine: Kisters SP060V, year 2000
  • Shrink-packer 3x2 (double lane), 60 cycles/min, manual lane width, foil only
• Conveyors & Pack labelling:
  • Bottle conveyor: KHS Innoline BTR, year 2000, plastic chain, dry lubrication
  • Pack conveyor: Paxona + Schaefer, year 2009
  • Pack labelling: Contact 100, self-adhesive label from reel
