Overview

This complete 1,500 L brewhouse system was manufactured by Spanish company Inox GC. It includes a three-vessel hot side, a 2,000 L mash/whirlpool tun, a 2,500 L lauter tun, and a 1,800 L hot water tank. The brewhouse comes with pumps, heat exchanger, CIP features, and a new AEM automatic gas burner for heating. The equipment is in good condition.

Technical data

• Brewhouse System – Inox GC (1,500 L)
  • Capacity per batch: 1,500 L
  • Vessels: HLT, mash/lauter tun, kettle/whirlpool
  • Material: AISI 304 stainless steel
  • Heating: Compatible with automatic gas burner
  • Includes: Temperature control panel, integrated pumps
• Isothermal Mash & Whirlpool Tun (2,000 L)
  • Capacity: 2,000 L
  • Insulation: 50 mm rock wool
  • Features: Hinged lids, agitator with VFD, CIP system, PT100 probe
• Isothermal Lauter Tun (2,500 L)
  • Capacity: 2,500 L
  • Features: 5° sloped bottom, 500 mm manway, German V-screen, automatic rake, CIP system
• Insulated Hot Water Tank (1,800 L)
  • Capacity: 1,800 L
  • Heating: 9 kW electric element
  • Features: Rock wool insulation, 50 mm inlet/outlet, CIP system
• Process Equipment
  • Wort pumps (helical & transfer)
  • Tubular heat exchanger (removable)
  • Hop filter
  • Automation panel with VFDs
• Automatic Gas Burner – AEM GR8 PHP (2016)
  • Type: Circular gas burner, automatic ignition
