KHS Innopas P II SG 30-200 Tunnel Pasteurizer (1996)

Overview

This KHS Innopas P II SG 30-200 is a tunnel pasteurizer for bottled beverages in glass bottles, built in 1996 by KHS (Klöckner Holstein Seitz, Germany). With a treatment area of 113.5 m² across 8 treatment zones (3 of them recuperative), it pasteurizes at approx. 24,000 - 25,000 bottles per hour depending on bottle format, at a maximum pasteurization temperature of 75 °C. For 0.7 l glass bottles the total treatment time is approx. 48.6 minutes (21.2 min heating, 12.3 min pasteurization, 15.0 min cooling) at approx. 5 pasteurization units.

The machine is controlled by a Siemens SIMATIC S5 PLC with Siemens touch panel and Danfoss frequency drives. It is completely dismantled and professionally stored, with the conveyor belt sections and components palletized - ready for immediate collection.

Technical data

• Manufacturer: KHS (Klöckner Holstein Seitz)
• Model: Innopas P II SG 30-200
• Year of manufacture: 1996
• Machine type: tunnel pasteurizer
• Capacity: approx. 24,000 - 25,000 bottles/hour (depending on bottle format)
• Treatment area: 113.5 m²
• Treatment zones: 8 (H1-H3, S, P, C1-C3 plus cooling tower zone), 3 recuperative
• Max. pasteurization temperature: 75.0 °C (0.7 l) / 72.5 °C (0.33 l)
• Inlet temperature: 15.0 °C; outlet temperature: approx. 32 - 38 °C depending on format
• Total treatment time: approx. 48.6 min (0.7 l) / 77.1 min (0.33 l)
• Pasteurization units: approx. 5 PE
• Machine water content: approx. 14.4 m³
• Water consumption at nominal capacity: approx. 1.5 m³/h
• Heat consumption at nominal capacity (0.7 l): approx. 3,672 MJ/h
• Installed power: approx. 66.2 kW
• Electrical connection: 400 V, 50 Hz
• Dimensions (L x W x H): approx. 21,000 x 4,210 x 2,750 mm
• Required entry opening: approx. 2.7 x 3.0 m
• Net weight: approx. 27,500 kg
• Noise level: ≤ 85 dB(A) according to ISO 3744

Equipment

• Siemens SIMATIC S5 PLC with Siemens touch panel
• Danfoss frequency drives
• Modular plastic conveyor belt with drainage openings, belt sections palletized
• External pump assemblies and inspection windows
• Electrical cabinets with main disconnect switch
• Original KHS documentation (datasheets and drawings)

Condition

Used. The machine is completely dismantled and stored; belt sections, piping and components are palletized for transport. The machine can be visited on request.

Availability

Immediately. Location: Germany. Loading by the seller is possible.
