Krones AirCo Air Conveyor (2011)

Overview

This Krones AirCo is an air conveyor for empty PET bottles, built at the end of 2011. The bottles hang by their neck ring and are driven by air from fan units along the conveyor. The installation runs over a total length of approx. 60 m with seven fan units, curves, a diverter and several declining sections.

The conveyor sections hang from stainless steel support stands and run at ceiling level across the hall, so the floor beneath stays free for traffic and other machines.

Technical data

• Manufacturer: Krones
• Model: AirCo
• Year of manufacture: 2011
• Machine type: air conveyor, neck handling of empty PET bottles
• Total conveyor length: approx. 60 m
• Declining sections: 10 sections at 10°, approx. 16.8 m in total
• Curves: 8 with radius 750 mm - 90° 2 x left, 2 x right; 45° left; 30° left; 15° left; 15° right
• Fan units: 7, each with filter housing
• Diverter: 1

Conveyor sections

In the order of the plant layout:

• Fan unit
• Straight section 3,500 mm
• Straight section 500 mm
• Curve 45° left, radius 750 mm
• Straight section 400 mm
• Straight section 2,000 mm
• Straight section 2,000 mm
• Fan unit
• Straight section 2,000 mm
• Straight section 1,000 mm
• Straight section 400 mm
• Straight section 300 mm
• Curve 30° left, radius 750 mm
• Straight section 2,000 mm
• Straight section 600 mm
• Straight section 400 mm
• Curve 15° left, radius 750 mm
• Straight section 1,500 mm
• Straight section 600 mm
• Straight section 500 mm
• Fan unit
• Straight section 1,500 mm
• Curve 15° right, radius 750 mm
• Straight section 2,000 mm
• Straight section 500 mm
• Straight section 600 mm
• Declining section 2,000 mm at 10°
• Declining section 1,500 mm at 10°
• Declining section 2,000 mm at 10°
• Declining section 2,000 mm at 10°
• Declining section 1,500 mm at 10°
• Straight section 1,500 mm
• Curve 90° left, radius 750 mm
• Straight section 1,500 mm
• Fan unit
• Straight section 2,000 mm
• Straight section 2,000 mm
• Straight section 400 mm
• Straight section 750 mm
• Curve 90° right, radius 750 mm
• Straight section 750 mm
• Straight section 400 mm
• Fan unit
• Declining section 2,000 mm at 10°
• Declining section 750 mm at 10°
• Declining section 2,000 mm at 10°
• Declining section 1,000 mm at 10°
• Declining section 2,000 mm at 10°
• Fan unit
• Straight section 1,000 mm
• Diverter
• Curve 90° left, radius 750 mm
• Fan unit
• Straight section 2,000 mm
• Straight section 750 mm
• Curve 90° right, radius 750 mm
• Straight section 1,500 mm
• Straight section 720 mm

Equipment

• Stainless steel conveyor channels with neck guide rails
• Stainless steel support stands and ceiling suspensions
• Fan units with air filters
• Sensors and pneumatic components along the conveyor
• Plant layout drawing of the installation

Condition

Used, currently installed in the plant. The bottle unscrambler visible in some photos is not included. Dismantling and the exact scope of delivery are agreed during the offer stage.

Availability

Available immediately. Location: Germany.
