V-Shapes PRIME Unit Dose Packaging (2021)

Overview

The packaging machine was manufactured in 2021 by the Italian manufacturer V-Shapes. This compact machine dispenses various products into single sachets between 0.5ml and 25ml. The scope of delivery also includes the printer, which allows the sachets to be produced in-house. The machine can be visited in operation at any time.

Technical Data

Packaging machine | V-Shapes | PRIME | 2021

• Production capacity: Up to 45 units/minute
• Time for packet size change: 15 minutes
• Number of packaging lines: 1
• Maximum dimensions of film reels: Width 110mm/ 4.33 ” Diameter 250 mm
• Weight of film reels: 20 kg / 44.09 lb
• Film reel consumption: Up to 2625 mm /min
• Standard weld dimensions: 5 mm(± 1 mm)
• Machine colour: Steel
• Electronic parts: Standard IP55, IP67 on request
• Standard electronics: PLC 6 brushless motors
                                     *Pneumatic dosage system: volumetric to measure
• Dimensions of V-Shapes packets: Height from 50 to 100mm/1.969” to 3.937”
• Width: from 40 to 100mm/1.575” to 3.937”
• Air Pressure: 7 bar
• Electric power: 20 Kwh
• Weight (maximum): 1000 kg / 6612lb
• Machine Footprint: 1500mm x 1000mm x 1000mm (H)

Printer | AstroNova | T2-C | 2022

• Print quality: 1600 x 1600 dpi or
• Print speed: 6 ips (152mm/sec) or 12 ips (300mm/sec)
• 4 external ink tanks á 2l
• Dimensions: 606mm x 580mm x 795mm
• Weight: 60 kg (without material)
