Overview

This PET filling line was manufactured in 2002 by Krones (Germany). The line is designed for carbonated beverages such as beer or lemonades, and also suitable for water with or without CO₂. With an output capacity of up to 12,000 bph (0.5 L), it offers a complete solution from bottle blowing to palletizing. The line is being sold due to modernization of the PET division and replacement with a higher-capacity system. Equipment is in good condition and still fully operational.

Technical data

• Line capacity:
  • 12,000 bph at 0.5 L
  • 9,000 bph at 1.0 L
  • 8,000 bph at 1.5 L
  • 6,000 bph at 2.0 L
• Formats: 0.5 L, 1.0 L, 1.5 L, 2.0 L
• Neck finish: PCO 1810
• Max. bottle diameter: 106 mm
• Products: Beer (+4 °C), Kvass and lemonades (+10 °C), still and carbonated water
• Labelling: Wrap-around, pre-cut paper labels, hot-melt
• Secondary packaging: Film only (4×3 and 3×2)
• PLC: Siemens S7-300
• Power supply: 400 V, 3PH, 50 Hz, TN-S

Scope of Delivery

• Blowing machine | Krones | Contiform S8 | 2002 | Incl. preform feeding, chiller, box titling unit
• Rinser | Krones | Variojet | 2002 | Rotary
• Filler | Krones | Mecafill | 2002 | Rotary, isobaric filler for CSD and beer
• Labeller | Krones | SV 360-10-113 | 2002 | Rotary
• Labeller | Krones | Canmatic 600-10 | 2002 | Rotary, hot-melt
• Packer | Krones | Variopac FS-45 | 2002 | Film packer, 4×3 / 3×2 formats
• Palletizer | Krones | Pressant Compact 1N | 2002
• Stretch wrapper | Robopac | Rotoplat | 2002
• Air conveyor | Krones | Airco S | 2002 | For blown PET bottles
• Bottle conveyor | Krones | Synco S | 2002 | For filled and labelled bottles
• Pack conveyor | Krones | Multico S | 2002 | For product packs
• Pallet conveyor | Krones | — | 2002 | For pallet transport
• Peripheral equipment | Krones | — | 2002 | Cap feeding system, hopper, valve manifold
