KHS INNOPAL,INNOFIL,INNOPRO, etc. Line for Cans (2012)

Overview

This high-performance can filling line was manufactured in 2012 by KHS and is designed for large-scale beverage production, particularly beer in aluminum cans. With a capacity of up to 48,000 cans per hour (500 ml), the line represents a modern, high-speed solution including depalletizing, filling, seaming, pasteurization, inspection, packaging, and palletizing. The core of the line consists of a KHS Innofill DVD 92 volumetric filler combined with a Ferrum F708G high-performance seamer, ensuring precise filling and reliable closing at maximum output rates. The line has been well maintained and remained in production until February 2026, and is available from Q1 2026. The overall installation features a compact, high-density layout with advanced conveyor and process integration, typical for modern KHS canning lines.

Technical Data

• Capacity: 48,000 cans per hour (500 ml) 41,000 cans per hour (568 ml)
• Container type: Aluminum cans
• Formats: 500 ml 568 ml
• Can dimensions: Diameter: 66.30 mm Height: 168 mm
• Lid specifications: Material: Aluminum Diameter: 59.44 mm Height: 2.07 mm
• Product: Beer
• Filling technology: Volumetric pressure filling with MID (magnetic inductive flow meters)
• Seaming technology: High-speed multi-head can seamer
• Pasteurization: Flash pasteurizer (KZE system)
• Condition: Very good condition, regularly maintained Availability: Q1 2026

Scope of Delivery

• Depalletizer | KHS | INNOPAL ASH-LD | Layer depalletizer with pallet lift; up to approx. 450 layers/h | 2012
• Filler | KHS | INNOFIL DVD 92 | Volumetric pressure filler with MID technology; up to 48,000 cph | 2012
• Seamer | Ferrum | F708G | High-speed can seamer with 8 stations; up to approx. 60,000 cph | 2012
• Lid Feed System | NSM Magnettechnik | – | Automated lid feeding and distribution system | 2012
• Flash Pasteurizer | KHS | INNOPRO KZE 250 | Continuous flash pasteurization with buffer tank | 2012
• CIP System | KHS | INNOPRO CIP | Multi-tank CIP system (1,000 – 3,000 L) | 2012
• Fill Height Inspector | KHS | Innocheck CUB | Fill level and closure inspection system | 2012
• Checkweigher | Radwag | DWT/RC 30 HP | Dynamic weight control system | 2012
• Shrink Packer | KHS | INNOPACK SP A-M | Film shrink packer; pad + film capability | 2012
• Pack Conveyor | KHS | INNOLINE GTR | Pack transport system | 2012
• Can Conveyor | KHS | INNOLINE BTR | Can transport system | 2012
• Pallet Conveyor | KHS | INNOLINE PTR | Pallet transport system | 2012
• Pallet Warehouse | KHS | INNOLINE MPH 1-1 | Pallet buffer and storage system | 2012
• Palletizer | KHS | INNOPAL PB1N1 | Automatic palletizing system | 2012
• Pallet Wrapper | ROBOPAC | Genesis Futura 40 | Automatic ring wrapper; up to 95 pallets/h | 2020
