Yaskawa, Profipack NX100 Palletizer and Depalletizer (2006)

Overview

This crate palletizing and depalletizing line was integrated in 2006 by Profipack Verpackungsmaschinen GmbH (Austria) around two Yaskawa Motoman NX100 articulated robots - one palletizing cell and one depalletizing cell - together with a Logipack vertical pallet strapper. It is still installed at a German brewery, where it palletized and depalletized crates for beer, CSD and mineral water production until the whole line was stopped. Because it served multiple product lines, it handles a wide variety of crate formats on Euro pallets. The machine can be visited on request.

Technical data

• Manufacturer / integrator: Logipack (vertical strapper), Profipack Verpackungsmaschinen GmbH (system integrator, Austria)
• Robots: 2x Yaskawa Motoman NX100 articulated robots (palletizer + depalletizer)
• Year of manufacture: 2006
• Machine type: crate palletizing and depalletizing line
• Capacity: 33,000 bph (160 bottles per layer)
• Pallet format: Euro
• Crate formats: 5x4 - 400x300x300 mm / 6x4 - 400x300x270 mm / 5x4 - 400x300x210 mm / 4x3 - 355x275x345 mm / 4x3 - 400x300x330 mm / 5x4 - 355x275x255 mm / 5x4 - 400x300x290 mm
• Controls: Siemens SIMATIC S7 PLC, B&R Power Panel HMI with ACOPOS servo drives, Danfoss VLT 5000 frequency drives, SEW MOVIDRIVE

Equipment

• Palletizer robot cell (Yaskawa Motoman NX100) with layer-gripper tooling
• Depalletizer robot cell (Yaskawa Motoman NX100) with layer-gripper tooling
• Logipack vertical pallet strapper
• Pallet and crate roller/slat conveyors
• Layer-forming / grouping table
• Unloading table
• Pallet magazine
• Separate BMS-branded control cabinet
• Safety fencing with light-curtain guarding

Condition

Used - complete, still installed; no longer in production (line stopped).

Availability

Available immediately. Location: Germany. Can be visited on request. Dismantling, handling, packing and truck loading can be quoted on request (EXW).
