Overview

This blowmoulder, filler and capper combiblock was manufactured by ACMI (Italy). The machine can be operated fully floor level and is a very good solution offering the advantage of a dual-cavity design (one mold = two bottles up to 70mm diameter) achieving an up to 17% reduced footprint vs equivalent output from traditional single-cavity equipment, improving production line accessibility. The increased output on smaller formats allows better utilisation of downstream equipment in the production line, resulting in improved ROI of total investment (100% additional output on smaller formats with less than 36% additional CAPEX).
The BLO2FILL ESF 12/120/20 is designed for the production of PET bottles and subsequent filling and capping in a single integrated system. The machine is suitable for carbonated water, still water and carbonated soft drinks.

Technical data

• Capacity: up to 48,000 bph (500 ml PET)
• Formats: 500 ml PET bottles
• Application: Blowing, filling and capping of PET bottles
• Configuration:
  • Rotary stretch blow moulding machine SBF412 (2-cavity configuration)
  • Electronic-volumetric filler with 120 valves
  • Fully electronic capper (FEC) with 20 heads
• Neck finish: 26/22 GME 30.40
• Cap type: Plastic screw flat / press-on caps
• Filling technology: Electronic-volumetric
• Products: Carbonated water, still water, carbonated soft drinks
• CO₂ content: up to 8.5 g/l
• Max. filling temperature: up to 18°C (carbonated water), 25°C ambient, 12°C (soft drinks)

Scope of Delivery

• Blowmoulder | Acmi | SBF412 | Rotary stretch blow moulding machine (2-cavity) - 100% r-PET and lightweight preform compatible
• Filler | Acmi | ESF | Electronic-volumetric filler with 120 valves
• Capper | Acmi | FEC | 20-head capper for screw and press-on caps
• Cap Feeder | Operator level waterfall orientation and feeding
• Preform orienter |Operator level preform feeding
• Preform insertion control | Control system
• Blowing air recovery system | For pre-blow and line
• Cooling system | Water recirculation on combo interface
• Automation package | PLC teleservice, Ethernet, UPS, remote access
• Lubrication system | Automatic centralized lubrication
• Foaming unit | Automatic system
