Overview

This rotary cold-glue labelling machine was manufactured in 2010 by the Spanish company Auxiemba. The model BASIC 600-10-CF-I-DR is designed for applying paper or polypropylene labels onto cylindrical glass bottles using cold-glue technology. It is equipped with formats for 330 ml, 500 ml, and 750 ml bottles, making it suitable for wineries, breweries, and beverage producers. The machine is being sold due to the closure of a production line and is available in very good working condition.

Technical data

• Capacity: up to 10,000 bottles/hour
• Bottle formats: 330 ml, 500 ml, 750 ml
• Bottle height range: 50–360 mm
• Bottle diameter range: 40–160 mm
• Label length range: 30–140 mm
• Rotation direction: Clockwise
• Number of bottle plates: 10
• Number of labelling stations: 1
• Air consumption: 125 L/min
• Power consumption: 17.3 kVA, 400 V
• Working height: 1,100 ± 50 mm
• Construction: Stainless steel frame, enclosed safety housing
• Control system: Micro PLC with touch-screen for speed, production, and fault management
• Key features:
  • Cold-glue labelling head with oil-bath lubricated mechanisms
  • Central carousel with centering bases for precise bottle positioning
  • Pneumatic heated pump for adhesive circulation and return system
  • Automatic bottle synchronization with infeed screw to prevent breakages
  • Micrometric glue adjustment to reduce film thickness and ensure clean labelling
  • Bottle retainers for smooth handling and reduced congestion
  • Gear-driven transmission with clutch and emergency stop system
  • Compact, fully enclosed design for hygiene and safety
