EUROSTAR SKILLFILL DPS 24-24-6C Line for Non-Returnable Glass Bottles (2014)

Overview

This complete isobaric filling line was produced in 2014 by the Italian manufacturer Eurostar and is located in Mexico. The line consists of a triblock (rinser, filler and capper), self-adhesive labeler and conveyor belts.

It is being sold because a new line with a higher capacity has been purchased. It has already been dismantled.

Technical Details

• Capacity: Max 6,000 b/h
• Formats:
  • 0.210L,
  • 0.355L,
  • 0.500L glass bottles
• 26mm metal crown caps
• Dimensions:
  • Width: 5,300 mm
  • Depth: 2,630 mm
  • Height: 2,860 mm
  • Weight: 8,000 kg
• POWER SUPPLY:
• Main: 460V – 60Hz – 3F+N+T
• Auxiliary: 24V DC
• Machine main motor: 4 kW
• Installed power: 9 kW

Scope of Delivery

• Triblock (rinser, filler, and capper)
• Selfadhesive Labeller with 2 stations
• Conveyors
