KHS asmofill ACF Line for Non-Returnable PET Bottles (2006)

Overview

The disposable PET-ACF line was manufactured by KHS in 2006. Most parts of the line are from KHS. Blow moulder is from Sidel and process department from GEA. The line is for sale, as the complete factory is closed. All machines were completely overhauled in 2021 and have only been in use for less than 5,000 working hours since then.

Technical specifications:

• PET bottle formats
  • 330 ml
  • 500 ml
  • 750 ml
  • 1.000 ml
  • 1.500 ml
  • 2.000 ml
• Suitable for juices and soft drinks with or without CO²
• Capacity
  • Non-carbonated drinks: up to 27,000 bph
  • Carbonated drinks: up to 21.800 bph
• Screw caps: 28mm & 38mm
• Control: Siemens S7
• Year of manufacture: 2006

The line in detail:

• Manufacturer: Sidel
  Machine type: Blow moulder
  Model: SBO 16
  Year of manufacture: 2006

• Manufacturer: KHS
  Machine type: Cap steriliser
  Model: SCS 8 Flatcap 28mm
  Year of manufacture: 2006

• Manufacturer: KHS
  Machine type: Cap steriliser
  Model: SCT 4 Flat 38 mm
  Year of manufacture: 2006

• Manufacturer: KHS
  Machine type: Filler
  Model: asmofill ACF 30-70-100-15
  incl. supply units for peroxide, sterile air, foam cleaning, UPS
  Year of manufacture: 2006

• Manufacturer: KHS
  Machine type: CIP/ SIP system
  Model: Innopro 1-500/2-3000/35 A
  Year of construction: 2006
  Capacity:

  • 40,000 l/h for CIP (cleaning temperature: approx. 85°C)

  • 20,000 l/h for SIP (sterilisation temperature: approx. 125°C)

• Manufacturer: KHS
  System for data acquisition and analysis
  Model: AIS MIDI

• Manufacturer KHS
  Machine type: Cap and fill level control system
  Model: METEC FMS BV
  Year of manufacture: 2006

• Manufacturer: KHS
  Machine type: Labeling machine
  Hot glue labeler
  Model: Innoket - SE 60/120 2 RF 1HS PT
  Year of manufacture: 2006

• Manufacturer: KHS
  Machine type: Label control system
  Model: METEC- ETK
  Year of manufacture: 2006
  Output signal error shutdown freely adjustable at:

  • Serial error

  • Cycle error

  • Number of bottles

• Manufacturer: KHS
  Type of machine: -container transport system
  Model: Innoline - BTR / P 30241/131
  Year of manufacture: 2006

• Manufacturer: KHS
  Machine type: Tray shrink packer
  Model: TSP 050 V TPFO

• Manufacturer: KHS
  Machine type: Carry handle applicator (CarryStripMaster)
  Model: CSM 050-2
  Year of construction: 2006

• Manufacturer: KHS
  Machine type: Tray packer
  Model: TP 035 B
  Basic format: 0.33 l PET bottles in 4x6 film packs (6x4) on tray
  Max. Machine speed: 35 cycles/ min
  Year of manufacture: 2010

• Manufacturer: KHS
  Machine type: Pack conveyor
  Model: Innoline - GTR / P 30241/131
  incl. turning station for large trays

• Process unit
  Manufacturer: GEA
  Deaerator, hot holder, flash pasteurizer (2x 16,000l), return tank, sterile tank
