KOSME Krones, KHS Line for Non-Returnable Glass Bottles (2013)

Overview

Complete filling line for non-returnable glass bottles with an output of approx. 16,000 bottles/h at 0.75 L and approx. 20,000 bottles/h at 0.33 L. The heart of the line is a KOSME BARIFILL RFC 50-60-10 VKP rinser-filler-capper block built in 2013. New glass is fed by a Krones sweep-off depalletizer from 2020; downstream, the line comprises Krones CHECKMAT cap control, a KHS INNOKET cold-glue labelling machine with camera-based label orientation, a Krones WRAPAPAC wrap-around packer and a GEA Procomac OPERA palletizing system with Robopac stretch wrapper and Logopack pallet labelling. An attractive mid-range line for water, soft drinks, beer, cider and other glass-bottle applications.

Technical data

• Year of manufacture: mainly 2013
• Capacity: approx. 16,000 bph at 0.75 L / approx. 20,000 bph at 0.33 L
• Application: filling and packaging of non-returnable glass bottles
• Filling system: short-tube VKP, 60 filling valves, 113 mm pitch
• Rinser: 50 stations, single-channel, 113 mm pitch
• Filler block electrical supply: 400 V, 50 Hz, 17 kW installed power, 38 A
• Filler block compressed air: 6 bar, approx. 450 Nl/min; water: 4 bar, approx. 3.5 m³/h
• Filler block weight: approx. 10,500 kg
• Integrated foam cleaning; touchscreen HMI on articulated suspension arm

Scope of Delivery

• Depalletizer | Krones | PRESSANT UNIVERSAL 1A | sweep-off depalletizer for new glass, servo-driven four-sided centering carriage, pallet lifting unit, approx. 5,000 mm discharge table, approx. 48,000 containers/h | 2020
• Rinser-filler-capper block | KOSME | BARIFILL RFC 50-60-10 VKP | stainless steel frame, transparent protective guarding with safety interlocks, process piping, layout drawing available | 2013
• Capper | Zalkin | CA9 360 NG | 10 capping positions, approx. 22,000 bottles/h; capping heads included | 2013
• Cap control | Krones | CHECKMAT
• Labelling machine | KHS | INNOKET KL2040/120-30 LM | cold glue, up to 26,000 bottles/h, camera system for label orientation, Siemens S7 control, new HMI touch panel 2019, formats incl. 0.33 L Longneck, Steinie and swing-top and 0.5 L NRW bottles | 2004
• Wrap-around packer | Krones | WRAPAPAC | 45 cartons/min, carton format e.g. 15 x 750 ml glass bottles, Nordson PROBLUE LIBERTY 14 hot-melt unit with automatic fill system | 2003
• Palletizer | GEA Procomac | OPERA | low-level infeed, automatic changeover of pallet patterns and pallet sizes, complete pallet conveying system, pallet magazine, mother pallet handling | 2009
• Stretch wrapper | Robopac
• Pallet labelling system | Logopack
• Conveyors | KOSME | bottle transport between the machines, line divider and discharge | 2013

Condition

Used. The core of the line is installed in an industrial production environment and still under power; the rinser-filler-capper block underwent extensive maintenance in Q4/2025 and can be visited and inspected in operation on request. The labelling machine was in production until January 2025, was overhauled in 2019 and is currently in storage. The line is composed of components from several production sites.

Availability

From mid-December 2026. Location: Germany.
