Krones Robot 3A Palletizer (2002)

Overview

This Krones / Robot 3A palletising robot, manufactured in 2003, is designed for the automatic palletising of beverage crates. The system is used to stack complete crate layers onto Euro pallets.The machine handles actually 1.0 l PET crates in an 8-crate layer pattern and is configured for crates with dimensions of 400 x 300 x 310 mm on Euro pallets measuring 1200 x 800 x 144 mm. During operation, the mechanical gripper head picks up complete layers of black beverage crates and places them onto pallets.The system is equipped with an MTS 10 operator panel, showing program operation, palletising status, and product configuration. The working area is protected by safety fencing and access doors.

Technical Data

• Manufacturer: Krones AG
• Machine Type: Robot palletising system / crate palletiser
• Machine Designation: Krones Robot 3A
• Year of Manufacture: 2003
• Application: Automatic palletising of PET beverage crates
• Layer Pattern: 8-crate scheme
• Crate Dimensions: 400 x 300 x 310 mm
• Pallet Format: Euro pallet, 1200 x 800 x 144 mm
• Handling System: Mechanical gripper head for complete crate layers
• Operation: Layer-by-layer palletising onto pallets
• HMI / Control Panel: MTS 10
• Conveyor System: Pallet roller conveyor with pallet magazine / pallet handling area
• Safety: Protective fencing, grid access doors, operator control panel and emergency stop
• Electrical Supply: 230 / 400 V AC Current Type: 3-phase Frequency: 50 Hz Nominal Current: 41 A
• Condition: Used, installed in industrial bottling / crate handling environment
