Krones, Sidel - Line for Non-Returnable PET Bottles (2002)

Overview

This complete filling and packaging line for PET bottles is designed for the production of CSDs and water. It operates at a capacity of 19,000 bph (with 1.5l) or 25,000 bph (with 0.5l). The line is still in operation and will become vacant in the summer of 2023 as it will be replaced by a larger line.

Individual machines

• Blowmoulder | Krones  | Contiform 16 | 2002
  • 16 cavities
  • Formats: 0,5l u. 1,5l
  • 12089 operating hours
  • Preform supply included
• Filler | Sidel | Alsim | 2002 or 2003
  • Blocked with screw capper
  • 100 rinsing nozzles
  • 140 valves
  • 20 screw capping positions
  • Siemens S7
  • With fill level control
• Labeller| Krones | Contiroll| 2003
  • Head machine
  •  2 labelling stations
  • 24 bottle plates
  • Hot glue
  • 15883 operating hours
  • Ink date coder
  •  Label inspection with pusher
• Shrink Packer | Krones | Variopac Pro | 2007
  • Packaging: Tray + Film
  • Formation: 2x3
  • Blocked with shrink oven
  • 33170 operating hours
  • 6 infeed lanes
  • Double lane output
• Handle applicator | TwinPack | Metel | 2001
• Palletizer | Krones | Robot 3A | 2001
  • Palletizing via column
  • Pack infeed at the bottom via 2 lanes
  • 1x clamping head
  • Euro and half pallet
  • 1x grouping table with transfer
  • Applicator and magazine for intermediate layer
• 2x Winders | Franpack | - | 2000
  • Cover layer application
• Mixer | Diessel | - | 2000
• Flash pasteurizer and water filtration
