Overview

This cold glue labeller was manufactured in 2012 by German company KRONES AG. The TOPMATIC is equipped with 42 bottle stations (pitch 125 mm) and was operated on 330 ml bottles. The machine is still installed with energy disconnected, stopped since September 2025, and can be visited on request. It has 48,121 operating hours. Regular maintenance was carried out (two overhauls per year), with the last overhaul in week 4/2025. No upgrades were made apart from replacing obsolete parts.

Technical data

• Capacity:
  • Max. 60,000 bph
  • Nominal 43,000 bph
• Formats:
  • 330 ml
• Labelling technology:
  • Cold glue
• Configuration:
  • 42 bottle stations
  • Pitch: 125 mm
• Inspection:
  • Label inspection system CHECKMAT (Krones)
• Dimensions:
  • approx. 430 × 340 × 245 cm
• Power supply:
  • 400 V, 20 A, 14 kW
