Newlands Systems Turnkey Brewery 35 hl Brewhouse (2011)

Overview

Complete turnkey craft brewery built around a 4-vessel Newlands Systems (NSI) brewhouse with a 35 hl brew length, delivered from Canada and installed in 2011-2013. The plant covers the full process chain: malt intake and milling, brewhouse, fermentation and maturation, yeast handling, CIP, steam and glycol cooling.

Fermentation capacity is 9 x 70 hl cylindroconical fermenters plus 2 x 70 hl pressure-rated bright beer tanks. The brewhouse runs on a Siemens Braumat control system. The brewery is still installed and under power and can be visited in operation.

Technical data

• Manufacturer: Newlands Systems (NSI), Canada
• Year of manufacture: 2011-2016
• Machine type: complete turnkey brewery, 4-vessel brewhouse
• Brew length: 35 hl
• Brewhouse vessels: mash mixer 44 hl, lauter tun 69.85 hl, boil kettle 58 hl, whirlpool
• Fermentation and maturation: 9 x 70 hl fermenters, 2 x 70 hl bright beer tanks
• Steam: 750 kW electric steam boiler, operating pressure approx. 4 bar
• Control system: Siemens Braumat
• Power supply: 3 x 400 V / 50 Hz

Scope of Delivery

• Brewhouse | Newlands Systems | 4-vessel, 35 hl brew length | Mash mixer, lauter tun with rakes, boil kettle with internal calandria, whirlpool, wort heat exchanger, progressive cavity grain-out and spent grains pumps, post-whirlpool solids filter | 2011
• Control system | Siemens | Braumat | Brewhouse control panel and operator station | 2011
• Hot liquor tanks | Newlands Systems | 2 x 60 hl, stacked | External steam heat exchanger, pumps and valving, 316 stainless wetted surfaces, water treatment dosing bin | 2012
• Fermenters | Newlands Systems | 9 x 70 hl working volume | Cylindroconical, 60 degree cones, standpipes, cooling jackets | 2012-2013
• Bright beer tanks | Newlands Systems | 2 x 70 hl working volume | Pressure rated, carbonation stone assemblies | 2012-2013
• Yeast storage tank | Newlands Systems | 700 l | Conical, cooling jacket, mixer | 2013
• Yeast propagator | Newlands Systems | 240 l working volume | 300 l total volume, AISI 304 stainless steel | 2012
• CIP station | Newlands Systems | Steam heating and pump | 2012
• Malt silo | MAFA Sweden | UNB 70 | 30 t capacity, outdoor installation | 2012
• Auger system | MAFA Sweden | Silo and mill connections, flexible auger, specialty grains dump hopper | 2012
• Malt mill | Bühler | 4-roller | 3.0 kW drive, ATEX marked | 2012
• Grist hopper | Newlands Systems | 1,000 kg | On load cells | 2012
• Electric steam boiler | Pannpartner | 750 kW | 3 x 400 V / 50 Hz, design pressure 16 bar, empty weight 800 kg, CE marked | 2011
• Glycol chiller | Daikin | Air-cooled water chiller, refrigerant R407C, 400 V | 2011
• Sterile air unit | Donaldson | 2016
• Pumps, fittings and accessories | 2012-2013

Condition

Used - still installed and under power, available for inspection in production.

Availability

Immediately. Location: Norway. Dismantling, handling, packing and truck loading can be quoted on request (EXW).
