PROMAC, SIPA, AROL, SMI Line for Non-Returnable PET bottles (2009)

Overview

This PET bottling line consists mainly of equipment from GEA Procomac, complemented by machines from Arol, VBC, SMI, TwinPak, Robopac, SIPA, Logopak, Domino, Ventilo and PE Labellers. The line was mainly manufactured in 2009, with several later additions and upgrades between 2013 and 2022, including the pallet wrapper, labelling machine, Domino laser coding system and extraction unit. The line is suitable for beverage production in PET bottles and includes the key process steps from air conveying, rinsing, filling and closing to nitrogen dosing, tray-shrink packing, handle application, palletizing, pallet wrapping, pallet labelling, sleeve labelling, coding and extraction.

Technical Data

• Line type: PET bottling line
• Capacity: 12.400 bottles/h
• Application: beverage filling in PET bottles
• Main manufacturer: GEA Procomac
• Main year of manufacture: 2009
• Later upgrades / additions: 2013 – 2022 f
• Formats: round bottle 0,5L; round bottle 0,75L; round bottle 1,5L (2 formats)
• Cap type: PCO 1881 1x FlatCap and 1x Sport
• Cap products: Flavoredwater still, Mineralwasser still, medium and classic
• Packaging: 0,5l 3x3; 0,75l 2x3; 1,5l 2x3
• Palletizing: Euro- und ½ Euro Palette
• Condition: Well maintained, extensive annual overhauls by the manufacturer

Scope of Delivery

• Blow Molding Machine | SIPA | SFR 8 | year tbd
• Filler | GEA Procomac | Filstar CX | 2009
• Rinser | GEA Procomac | Gripstar ACE | 2009
• Capping | Arol | TS Euro PK “Washable” 10K | 2009
• Nitrogen Dosing | VBC | Nitrodose 49000 MS System | 2009
• Bottle Dryer | Ventilo | – | 2009
• Labelling Machine | PE Labellers | Adhesleeve 540-12-CI3-375 | 2016
• Tray-Shrink Packer | SMI | SK 450T | 2009
• Handle Applicator | TwinPak | MDEL-S | 2009
• Tray Packer | SMI | TF 350 | 2009
• Palletizer | GEA Procomac | Opera 100 | 2009
• Pallet Wrapper | Robopac | Genesis HS Top | 2009
• Pallet Wrapper | Robopac | Helix HS30 | 2013
• Pallet Labeller Slave | Logopak | Logomatic 920 II PFR VLP210 | 2009
• Pallet Labeller Master | Logopak | Logomatic 920 II PFR VLP210 | 2011
• Air Conveyor | GEA Procomac | – | 2009
• Tray Conveyor | GEA Procomac | – | 2009
• Bottle Conveyor | GEA Procomac | – | 2009
• Domino Laser | Domino | D120i 10 Blue Standard BCP7 | 2022
• Extraction System | Domino | DPX1000 | 2015
