Overview

The machine was built in 2012 and used in a fruit juice company. With the briquetting press BrikPress almost all recyclable materials that can be compacted, such as cardboard, polystyrene, aluminum, plastics, PET bottles, etc., can be pressed into briquettes for later recycling or thermal purposes. Special features of the BrikPress: – Fully automatic operation – Designed for automatic and manual feeding – Feeding possible during the pressing process – Can be operated laterally by a single person.

Tech Specs:

• Feeding opening
  W x L: 600 x 950 mm
• Size L x W x H:
  4195 x 1434 x 2562 mm
• Footprint approx. 3.2 m²
  without ejection chute
• Weight press approx. 1800 kg
• Operating voltage: 400 V / 3 ph / 50 Hz
• Motor power: 9,2 kW
• Protection class: IP 54
• Press weight: 300 kN
• Briquette dimension W x H x L:
  80 x 80 x 100-300 mm
• Briquette weight: approx. 600 kg/m³,
  depending on material, e.g. cardboard adjustable from 200 – 600 kg/m³

Features:

• Suitable for indoor and outdoor operation
