Teycomur Maquinaria LLV Atmospheric filler (2015)

Overview

This Teycomur LLV atmospheric gravity filler, manufactured in 2015, is designed for filling bottles or jars with liquid to viscous products. The machine is equipped with 8 filling heads and an integrated single-head screw capper, making it suitable for small to medium-scale production of food and beverage products. The system is designed to handle different product densities, ranging from juice-type liquids up to marmalade-like products. It can process formats of 250 ml, 750 ml and 1 l, with adapters included for each format. A stainless steel hopper and an automatic cap dispensing system are also included.The machine is built in stainless steel with transparent safety guarding and an integrated conveyor system. It is controlled via a Unitronics controller, while the electrical cabinet includes components such as an Allen-Bradley PowerFlex 4M frequency drive, Weidmüller 24 V power supply and Pilz safety relay. The machine is CE-marked and was observed in a clean industrial production environment.

Technical Data

• Manufacturer: Teycomur Maquinaria
• Model: LLV
• Machine Type: Atmospheric gravity filler with screw capper
• Year of Manufacture: 2015
• Capacity: approx. 1,000 bottles/hour
• Filling System: Atmospheric gravity filling
• Number of Filling Heads: 8 Capping System: 1-head screw capper
• Compatible Formats: 250 ml, 750 ml and 1 l
• Product Compatibility: Liquids with variable density, from juice to marmalade
• Included Format Parts: Adapters for each format
• Included Components: Stainless steel hopper and automatic cap dispenser
• Control System: Unitronics controller with integrated display and keypad
• Drive System: Allen-Bradley / Rockwell Automation PowerFlex 4M frequency drive
• Safety Components: Pilz safety relay, emergency stop and protective guarding
• Construction: Stainless steel frame with transparent safety doors
• Conveyor System: Linear stainless steel bottle conveyor with guide rails
• Condition: Used, installed in industrial production environment
