Cimec MONDIAL MONOBLOCK LD 9/8 monoblock (2017)

Overview

This filling monoblock was manufactured in 2017 by CIMEC. The machine is designed for filling applications in the liquor and spirits industry. The machine is currently still installed and can be visited on request.

Technical data

• Capacity: approx. 3,000 bottles per hour
• Application: Filling (liquor / spirits)
• Configuration: Model MONDIAL MONOBLOCK LD 9/8
• Filling System: Gravity filling
• Number of Filling Valves: 8
• Number of Rinsing Nozzles: 9
• Number of Labelling Heads: 1
• Sealing: It applies heat shrink capsules on the neck
• Water Pressure (Rinsing): 2 – 3 bar
• CIP Cleaning Temperature: up to 80°C (water) / 100°C (steam at low pressure)
• Electrical Supply: 400V, 50Hz, 3-phase
• Components & Features:
  • Rinsing & Filling Section:
    • 9-head bottle rinser with “No Bottle / No Spray” system
    • 8-valve gravity filler with adjustable filling level
    • Electrical regulation of filling height and level
    • Support system for heavy bottles
    • Automatic tank level control via sensors
    • Compatible with multiple bottle neck formats (including change parts)
  • Labeling & Sealing Unit:
    • Self-adhesive labeler (1 head)
    • Optical label centering system for precise application
    • Capability to apply label and back label on the same bottle
    • Automatic capsule dispenser with thermal sealing head
    • Guides and supports for multiple cylindrical bottle formats
  • Control & Operation:
    • Touchscreen interface with electronic control
    • Adjustable production speed (manual and automatic modes)
    • Entry and exit bottle sensors
    • Integrated safety systems with automatic stop functions
    • CIP (Cleaning in Place) function for internal cleaning and sanitation
