Ferrero AV 9/12/1VA Triblock (2026)

Overview

This Ferrero AV 9/12/1VA automatic triblock, built in 2026, is designed for filling vegetable edible oil into Marasca-type glass bottles. The block combines a 9-clamp air rinsing station, a 12-valve high-vacuum filling station and an AROL EAGLE VA-IES single-head capping station for ROPP 31.5 x 24 mm aluminum screw caps in one compact AISI 304 stainless steel machine with a nominal output of 2,000 bottles/hour (750 ml).

The machine is new and unused. Format tooling for four Marasca sizes (250 / 500 / 750 / 1,000 ml), nitrogen injection before capping, a 7-inch Siemens SIMATIC HMI touchscreen in English and remote diagnostics via Ethernet are included - ready for immediate use.

Please note: an optional mechanical caps elevator is available on request; it is not included in the sale price.

Technical data

• Manufacturer: Ferrero (Italy)
• Model: AV 9/12/1VA
• Year of manufacture: 2026
• Machine type: rinser - filler - capper triblock for glass bottles
• Product: vegetable edible oil, ambient filling temperature
• Rinsing: 9-clamp air rinsing turret
• Filling: 12-valve high-vacuum filling turret
• Capping: AROL EAGLE VA-IES single head, ROPP 31.5 x 24 mm aluminum caps
• Capacity: 2,000 bottles/hour nominal (750 ml)
• Bottle formats: Marasca 250 / 500 / 750 / 1,000 ml (tooling included)
• Bottle diameter range: 55 - 110 mm; height range: 180 - 350 mm
• Control: 7-inch Siemens SIMATIC HMI touchscreen (English)
• Electrical supply: 400 V three-phase, 50 Hz; 8 kW installed power
• Compressed air: approx. 435 Nl/min at 6 bar
• Construction: AISI 304 stainless steel; CE marking

Equipment

• Air rinsing station with AISI 304 grippers, EPDM pads and maintenance-free TWIST rotation
• High-vacuum filling station in AISI 304 and food-grade materials, steam or chemical sterilizable
• Polished AISI 304 product tank with level indicator, height adjustment and tool-free lid
• AROL capping station with vibrating cap dispenser, cap level detector and missing-cap detection
• Worm screws, star wheels and conveyors for Marasca formats
• Nitrogen injection before capping (gas supply by the customer)
• Photocells at inlet and outlet, remote diagnostics via Ethernet
• Full AISI 304 safety enclosure with LEXAN inspection doors and safety microswitches

Condition

New - built in 2026. The machine can be viewed and tested in operation on request.

Availability

Immediately available. Location: Italy.
