KOSME Barifill RFC 50-60-10 VKP Isobaric Filler Capper (2013)

Overview

This KOSME Barifill RFC 50-60-10 VKP rinser - filler - capper block, built in 2013, is designed for the rinsing and filling of glass bottles in beverage production lines. The block combines a 50-station single-channel rinser, a 60-valve glass bottle filler with short-tube VKP filling system and a Zalkin CA9 360 NG rotary capping section in one compact stainless steel machine.

With approx. 16,000 bottles/hour on 0.75 L and approx. 20,000 bottles/hour on 0.33 L, the block sits in an attractive mid-range capacity class for water, beer, cider, wine and other glass-bottle applications. Integrated foam cleaning supports hygienic operation; the machine is operated via a touchscreen HMI on an articulated suspension arm and is enclosed in transparent protective safety guarding with safety interlocks. The machine is still installed and under power and underwent extensive maintenance in Q4/2025.

Please note: the Zalkin capping heads are not included in the sale - the capper base machine is included, the 10 capping heads will be reused by the seller and must be sourced by the buyer.

Technical data

• Manufacturer: KOSME S.r.l.
• Model: Barifill RFC 50-60-10 VKP
• Year of manufacture: 2013
• Machine type: rinser - filler - capper block for glass bottles
• Filling system: short-tube VKP, 60 filling valves, 113 mm pitch
• Rinser: 50 stations, single-channel, 113 mm pitch
• Capper: Zalkin CA9 360 NG (2013), 10 capping positions, approx. 22,000 bottles/hour (capping heads not included)
• Capacity: approx. 16,000 bph at 0.75 L / approx. 20,000 bph at 0.33 L
• Foam cleaning: integrated
• Control: touchscreen HMI on articulated suspension arm
• Electrical supply: 400 V, 50 Hz, 17 kW installed power, 38 A
• Compressed air: 6 bar, approx. 450 Nl/min
• Water: 4 bar, approx. 3.5 m³/h
• Machine weight: approx. 10,500 kg

Equipment

• KOSME Barifill RFC 50-60-10 VKP main machine
• 50-station single-channel rinser
• 60-valve glass bottle filler, short-tube VKP filling system
• Integrated foam cleaning
• Zalkin CA9 360 NG capper base machine
• Touchscreen HMI on articulated suspension arm
• Stainless steel machine frame with transparent protective guarding and safety interlocks
• Process piping, vacuum / air equipment, stainless steel bottle handling
• Layout drawing available
• Not included: Zalkin capping heads (reused by the seller)

Condition

Used - installed in an industrial production environment and still under power. The machine underwent extensive maintenance in Q4/2025 and can be visited and inspected in operation on request.

Availability

From November 2026 (week 45). Location: Germany.
