Overview

This rinser-filler-capper bloc was manufactured in 2003 by Kosme. The bloc is designed for filling carbonated and non-carbonated beverages in PET bottles. It includes a rinsing machine with 2 channel and an isobaric filler with integrated capper for plastic screw caps. The machine is currently available promptly, and further information is available upon request.

Technical data

• Capacity:
  • 10,000 bottles per hour
• Formats:
  • 1,0 l PET bottles
  • 0,5 l PET bottles
  • 0,33 l PET bottles
• Working direction:
  • Clockwise
• Rinsing system:
  • 36 rinsing nozzles
  • 2 channel rinser
  • With stainless steel pipes
• Filling system:
  • Isobaric system
  • 36 filling valves
• Capping system
  • Manufacturer: Arol
  • 9 capping heads
  • With 2 cap chutes, 1 for 28 mm plastic caps, 1 for sport caps

Scope of Delivery

• Rinser, filler, capper in triblock construction
• Vacuum barrier system
• Stainless steel CIP cups
• Cap feeding system
