KHS Innopro Warmer-Cooler Combined Processing Unit (2006)

Overview

This KHS Innopro warmer-cooler is a skid-mounted thermoregulator for wine, built in 2006 by KHS AG in Dortmund, Germany. It brings wine to a set temperature, heating or cooling as required, at up to 9,900 l/h (99 hl/h), designed for an outlet temperature of 18 °C. The core is a three-section Thermowave plate heat exchanger; stainless steel piping, pumps, pneumatically operated valves and instrumentation are mounted on one frame and run from a freestanding KHS stainless steel control cabinet with touch panel. The unit was last used in a wine bottling line.

Technical data

• Manufacturer: KHS AG (Dortmund, Germany)
• Model: Innopro warmer-cooler
• Year of manufacture: 2006 (control cabinet 2007)
• Machine type: thermoregulator for heating or cooling wine, skid-mounted
• Product: wine
• Throughput: 9,900 l/h (99 hl/h)
• Cooling section: wine from 26 °C to 18 °C, cold water 10 °C to 14 °C at 18,328 l/h
• Heating section: wine from 9 °C to 18 °C via a warm-water circuit (25 °C to 21 °C, 20,516 l/h), which is heated by hot water from 100 °C to 55 °C
• Plate heat exchanger: Thermowave, 3 sections, 71 plates, total heat transfer area 6.1 m²
• Plate heat exchanger ratings: operating pressure 10 bar, test pressure 12.5 bar, max. operating temperature 100 °C
• Power supply: 400 V, 50 Hz, 3/N/PE, rated current 25 A; control voltage 24 V DC
• Overall dimensions: approx. 3,100 x 1,850 x H 2,330 mm

Equipment

• Thermowave plate heat exchanger with cooling, wine heating and warm-water heating sections
• Warm-water circuit and membrane expansion vessel
• Centrifugal pumps, including a Hilge stainless steel pump
• Pneumatically operated valves and a pneumatic control valve with positioner
• Pressure gauges and process instrumentation
• Freestanding KHS stainless steel control cabinet with touch panel
• Stainless steel skid frame with interconnecting piping

Condition

Used. Still installed and can be inspected by appointment.

Availability

Immediately. Location: Belgium.
