Represa LAGUI 3.2 Self Adhesive Labeler (2016)

Overview

This Represa LAGUI 3.2 is an automatic rotary labeling machine for self-adhesive labels on cylindrical bottles, built in 2016 by the Spanish manufacturer Represa Construcciones Mecánicas. It has been used for wine bottling and is configured with three labeling heads for front label, back label and tax strip stamp on 75 cl and 150 cl wine bottles.

The bottles are spaced by an infeed screw, transferred by starwheels onto rotating bottle plates and labeled in sequence by the three heads; each head is adjustable in height, angle and travel. Bottle height is set automatically from the touch panel, and up to 30 formats (bottle heights and label sets) can be stored and recalled for fast changeovers.

Technical data

• Manufacturer: Represa Construcciones Mecánicas
• Model: LAGUI 3.2
• Year of manufacture: 2016
• Machine type: rotary self-adhesive labeler for cylindrical bottles
• Labeling heads: 3 (front label, back label, tax strip stamp)
• Output: up to 3,000 bottles per hour, adjustable
• Bottle formats: 75 cl and 150 cl
• Format memory: up to 30 formats
• Power supply: 400 V
• Compressed air: 2.5 bar minimum operating pressure
• Construction: stainless steel frame with transparent safety guarding

Equipment

• Bottle infeed screw and transfer starwheels
• Rotating bottle plates
• 3 self-adhesive labeling heads with label detection sensors
• Photoelectric bottle detection
• Automatic height adjustment of the machine and the heads
• Control panel with multifunction touch screen on a 180° swivel arm
• Safety-interlocked doors and emergency stop
• CE declaration and operating manual (Spanish)

Condition

The machine is still installed and can be inspected on site by appointment.

Availability

Available immediately. Location: Spain.
