Overview

This vacuum evaporator was manufactured in 2018 by Italian manufacturer REDA.

The machine is designed for gentle concentration of musts, juices, and other liquid products at low temperatures to preserve aromas and product quality. It is almost new and offered for sale as it was intended for a project that did not proceed. The system features an automated, CIP‑ready design.

Technical data

• Capacity: 100 L/h evaporation capacity at +22/+24 °C
• Application: Concentration of musts, juices, and liquid products
• Operating modes: Recirculation mode or direct concentration mode
• Max. concentration: 55–70 °Brix
• Daily output: 2,400 L evaporated / 24,000 L enriched to 10%
• Utilities:
  • Electrical supply: 25 kW, 380 V / 3Ph / 50 Hz + PE
  • Water: +12/+18 °C (low consumption)
  • Compressed air: 6–8 bar
• Connections: DN40 DIN, 50 mm hoses
• Control system: PLC automation, IP65 control cabinet, digital temperature indicators

Scope of Delivery

• Vacuum evaporator | REDA | CM100 | 2018 | Complete AISI stainless-steel construction
• Evaporation chamber | Stainless steel, full inspection access
• Heat exchanger | AISI 316L tubular exchanger
• Vacuum pump | Liquid-ring system with cooling recirculation
• Refrigeration group | Heating 75,000 kcal/h, cooling 60,000 frig/h, 2 × 12.5 HP Copeland compressors
• Pumps | Stainless-steel centrifugal and mono volumetric discharge pump
• Vapor condenser | Stainless-steel surface condenser
• Instrumentation & tanks | Flowmeters, cold and hot water stainless-steel accumulation tanks
